Abstract
Mold products are precision machinery, it mainly consists of mechanical parts and bodies，such as forming working parts, parts orientation, positioning parts, supporting parts, positioning components and feed mechanism, core-pulling mechanism, introduced institutions. Mold and the corresponding forming equipment supporting the use of, may directly alter the shape of metal or non-metallic materials, size, relative position and performance, shaping the work piece for qualified.
In the first part of the document mainly describes the development of stamping die, stamping die illustrate the importance and significance of this design, and then stamping parts of the process analysis, completed a process to identify programs. The second part of the nesting parts of the design plans to complete the calculation of the utilization of the material further edge blanking process of calculation and Die Design and Calculation of the work of some of the stamping equipment to provide a basis to choose. Finally, the main components of standard design and the choice of design-based mapping tool and provide a basis for forming mold, as well as the assembly drawing to provide the basis of the size. Through the draw in front of mold design and assembly of the parts diagram Fig.
目錄
摘要 2
Abstract 3
1.緒論 6
1.1 模具研究的意義 6
1.2 沖壓技術的發展 6
1.3 沖壓工藝的基本工序和分類 7
1.4 沖壓成型的特點 7
1.5 此次沖壓模具設計的目的和意義 8
2 零件沖壓工藝分析 9
2.1 材料工藝性分析 9
2.2 零件結構 10
2.3 尺寸精度分析 10
2.4 分析制造零件所需方案 10
2.5 方案的比較 10
2.6 方案的確定 10
2.7 工序的確定 11
3 工藝計算 13
3.1 排樣的設計與計算 13
3.1.1 毛坯形狀的確定 13
3.1.2 毛坯尺寸確定 13
3.1.3 確定搭邊 14
3.1.4 確定條料寬度 14
3.1.5 確定條料的進距 15
3.1.6 材料的利用率 15
3.1.7 排樣圖 15
3.2落料的相關計算 16
3.2.1 落料所需沖裁力、卸料力、頂件力、推件力的確定 16
3.2.2 沖裁模刃口尺寸計算 17
3.3 拉深相關計算 19
3.3.1 拉深次數的確定 19
3.3.2 拉深所需拉深力、壓料力、彎曲力、翻邊力的計算 20
3.3.3 拉深模工作部分尺寸計算 21
3.4 壓力中心的確定 22
4 模具結構與零件的設計 23
4.1 模具結構形式的確定 23
4.2 模具零件的設計 24
4.2.1 凸模、凹模的確定 24
4.2.2 壓邊圈的確定 25
4.2.3 卸料版的確定 25
4.2.4 推件塊的確定 25
4.2.5 定位零件的選擇 26
4.2.6 緊固零件的選擇 26
4.2.7 模架的選擇 26
4.2.8 導向零件的選擇 27
4.2.9 模柄的選擇 27
4.3 凸模、凹模高度及強度校核 27
4.3.1 高度確定 27
4.3.2 強度校核 28
4.3.3 確定模具的總高度 29
4.4 繪制模具裝配圖及非標準件零件圖 29
5 使用SoildWorks繪制三維圖 30
6 設計總結 31
7 參考文獻 33
