機械生產是研究產品設計、生產、加工制造、銷售使用、維修服務和回收再生的整個過程的工程學科。現代機械生產技術越來越發達，但在新型的生產動力普遍使用之前，原有的成熟生產條件依然被使用，在機械生產過程中發揮著重要的作用。
2105柴油機是機械生產中廣泛應用的生產設備，轉速器盤做為其中連接手動裝置和油門，實現無級變速的重要零件，是不可替代的部件。對其進行分析計算，并根據結果選用相應的加工機床，設計相應的夾具，是本次畢業設計的主要內容。
設計從轉速器盤的整體分析開始，經過毛壞選料、工藝分析、確定加工規程，再逐一對要加工的表面進行詳細的計算，并查找工具書籍進行機床刀具等的選用。最后選取零件上的Φ10mm的孔進行了加工夾具的設計。
關鍵詞：機械傳動 轉速器盤 夾具設計
The Plate Processing Technology and Its Speed Fixture Design
Student: BIN Shang-wen Teacher: DAI xuan-jun
Abstract: Mechanical production is the study of product design, production, manufacture, sale, repair and regeneration of the whole process of engineering disciplines will be added. Modern machinery manufacturing technology more and more developed, but in power prior to the large-scale use of new production, original mature production conditions are still being used, in machinery production plays an important role in the process. 2105 mechanical equipment used in the production of diesel engines, speed disk for which connection manual installation and the gas, important part to realize continuously variable, is irreplaceable part. Analysis and calculation of its, and selected according to the results of the processing machine tools, design the appropriate fixture, is the main content of this graduation. Designed starting from the overall analysis of the speed, after bad materials, process analysis, determine the processing rules and detailed calculations of the surface to be processed one by one, and find the tools selection of books, such as machine tools. Φ10mm on the last selected part design of fixture for hole machining.
Key words： mechanical transmission tachometer disk fixture design
目次
